LabVIEW - Industrial Dual 0-20mA Bricklet 2.0

This is the description of the LabVIEW API bindings for the Industrial Dual 0-20mA Bricklet 2.0. General information and technical specifications for the Industrial Dual 0-20mA Bricklet 2.0 are summarized in its hardware description.

An installation guide for the LabVIEW API bindings is part of their general description.

API

Generally, every function of the LabVIEW bindings that outputs a value can report a Tinkerforge.TimeoutException. This error gets reported if the device did not respond. If a cable based connection is used, it is unlikely that this exception gets thrown (assuming nobody plugs the device out). However, if a wireless connection is used, timeouts will occur if the distance to the device gets too big.

The namespace for all Brick/Bricklet bindings and the IPConnection is Tinkerforge.*.

Basic Functions

BrickletIndustrialDual020mAV2(uid, ipcon) → industrialDual020mAV2
Input:
  • uid – Type: String
  • ipcon – Type: .NET Refnum (IPConnection)
Output:
  • industrialDual020mAV2 – Type: .NET Refnum (BrickletIndustrialDual020mAV2)

Creates an object with the unique device ID uid. This object can then be used after the IP Connection is connected (see examples above).

BrickletIndustrialDual020mAV2.GetCurrent(channel) → current
Input:
  • channel – Type: Byte, Range: [0 to 1]
Output:
  • current – Type: Int32, Unit: 1 nA, Range: [0 to 22505322]

Returns the current of the specified channel.

It is possible to detect if an IEC 60381-1 compatible sensor is connected and if it works probably.

If the returned current is below 4mA, there is likely no sensor connected or the connected sensor is defective. If the returned current is over 20mA, there might be a short circuit or the sensor is defective.

If you want to get the value periodically, it is recommended to use the CurrentCallback callback. You can set the callback configuration with SetCurrentCallbackConfiguration().

BrickletIndustrialDual020mAV2.SetChannelLEDConfig(channel, config)
Input:
  • channel – Type: Byte, Range: [0 to 1]
  • config – Type: Byte, Range: See constants, Default: 3

Each channel has a corresponding LED. You can turn the LED off, on or show a heartbeat. You can also set the LED to "Channel Status". In this mode the LED can either be turned on with a pre-defined threshold or the intensity of the LED can change with the measured value.

You can configure the channel status behavior with SetChannelLEDStatusConfig().

The following constants are available for this function:

For config:

  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_OFF = 0
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_ON = 1
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_SHOW_HEARTBEAT = 2
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_SHOW_CHANNEL_STATUS = 3
BrickletIndustrialDual020mAV2.GetChannelLEDConfig(channel) → config
Input:
  • channel – Type: Byte, Range: [0 to 1]
Output:
  • config – Type: Byte, Range: See constants, Default: 3

Returns the channel LED configuration as set by SetChannelLEDConfig()

The following constants are available for this function:

For config:

  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_OFF = 0
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_ON = 1
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_SHOW_HEARTBEAT = 2
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_CONFIG_SHOW_CHANNEL_STATUS = 3
BrickletIndustrialDual020mAV2.SetChannelLEDStatusConfig(channel, min, max, config)
Input:
  • channel – Type: Byte, Range: [0 to 1]
  • min – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 4000000
  • max – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 20000000
  • config – Type: Byte, Range: See constants, Default: 1

Sets the channel LED status config. This config is used if the channel LED is configured as "Channel Status", see SetChannelLEDConfig().

For each channel you can choose between threshold and intensity mode.

In threshold mode you can define a positive or a negative threshold. For a positive threshold set the "min" parameter to the threshold value in nA above which the LED should turn on and set the "max" parameter to 0. Example: If you set a positive threshold of 10mA, the LED will turn on as soon as the current exceeds 10mA and turn off again if it goes below 10mA. For a negative threshold set the "max" parameter to the threshold value in nA below which the LED should turn on and set the "min" parameter to 0. Example: If you set a negative threshold of 10mA, the LED will turn on as soon as the current goes below 10mA and the LED will turn off when the current exceeds 10mA.

In intensity mode you can define a range in nA that is used to scale the brightness of the LED. Example with min=4mA and max=20mA: The LED is off at 4mA and below, on at 20mA and above and the brightness is linearly scaled between the values 4mA and 20mA. If the min value is greater than the max value, the LED brightness is scaled the other way around.

The following constants are available for this function:

For config:

  • BrickletIndustrialDual020mAV2.CHANNEL_LED_STATUS_CONFIG_THRESHOLD = 0
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_STATUS_CONFIG_INTENSITY = 1
BrickletIndustrialDual020mAV2.GetChannelLEDStatusConfig(channel) → min, max, config
Input:
  • channel – Type: Byte, Range: [0 to 1]
Output:
  • min – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 4000000
  • max – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 20000000
  • config – Type: Byte, Range: See constants, Default: 1

Returns the channel LED status configuration as set by SetChannelLEDStatusConfig().

The following constants are available for this function:

For config:

  • BrickletIndustrialDual020mAV2.CHANNEL_LED_STATUS_CONFIG_THRESHOLD = 0
  • BrickletIndustrialDual020mAV2.CHANNEL_LED_STATUS_CONFIG_INTENSITY = 1

Advanced Functions

BrickletIndustrialDual020mAV2.SetSampleRate(rate)
Input:
  • rate – Type: Byte, Range: See constants, Default: 3

Sets the sample rate to either 240, 60, 15 or 4 samples per second. The resolution for the rates is 12, 14, 16 and 18 bit respectively.

Value Description
0 240 samples per second, 12 bit resolution
1 60 samples per second, 14 bit resolution
2 15 samples per second, 16 bit resolution
3 4 samples per second, 18 bit resolution

The following constants are available for this function:

For rate:

  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_240_SPS = 0
  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_60_SPS = 1
  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_15_SPS = 2
  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_4_SPS = 3
BrickletIndustrialDual020mAV2.GetSampleRate() → rate
Output:
  • rate – Type: Byte, Range: See constants, Default: 3

Returns the gain as set by SetSampleRate().

The following constants are available for this function:

For rate:

  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_240_SPS = 0
  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_60_SPS = 1
  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_15_SPS = 2
  • BrickletIndustrialDual020mAV2.SAMPLE_RATE_4_SPS = 3
BrickletIndustrialDual020mAV2.SetGain(gain)
Input:
  • gain – Type: Byte, Range: See constants, Default: 0

Sets a gain between 1x and 8x. If you want to measure a very small current, you can increase the gain to get some more resolution.

Example: If you measure 0.5mA with a gain of 8x the return value will be 4mA.

The following constants are available for this function:

For gain:

  • BrickletIndustrialDual020mAV2.GAIN_1X = 0
  • BrickletIndustrialDual020mAV2.GAIN_2X = 1
  • BrickletIndustrialDual020mAV2.GAIN_4X = 2
  • BrickletIndustrialDual020mAV2.GAIN_8X = 3
BrickletIndustrialDual020mAV2.GetGain() → gain
Output:
  • gain – Type: Byte, Range: See constants, Default: 0

Returns the gain as set by SetGain().

The following constants are available for this function:

For gain:

  • BrickletIndustrialDual020mAV2.GAIN_1X = 0
  • BrickletIndustrialDual020mAV2.GAIN_2X = 1
  • BrickletIndustrialDual020mAV2.GAIN_4X = 2
  • BrickletIndustrialDual020mAV2.GAIN_8X = 3
BrickletIndustrialDual020mAV2.GetSPITFPErrorCount() → errorCountAckChecksum, errorCountMessageChecksum, errorCountFrame, errorCountOverflow
Output:
  • errorCountAckChecksum – Type: Int64, Range: [0 to 232 - 1]
  • errorCountMessageChecksum – Type: Int64, Range: [0 to 232 - 1]
  • errorCountFrame – Type: Int64, Range: [0 to 232 - 1]
  • errorCountOverflow – Type: Int64, Range: [0 to 232 - 1]

Returns the error count for the communication between Brick and Bricklet.

The errors are divided into

  • ACK checksum errors,
  • message checksum errors,
  • framing errors and
  • overflow errors.

The errors counts are for errors that occur on the Bricklet side. All Bricks have a similar function that returns the errors on the Brick side.

BrickletIndustrialDual020mAV2.SetBootloaderMode(mode) → status
Input:
  • mode – Type: Byte, Range: See constants
Output:
  • status – Type: Byte, Range: See constants

Sets the bootloader mode and returns the status after the requested mode change was instigated.

You can change from bootloader mode to firmware mode and vice versa. A change from bootloader mode to firmware mode will only take place if the entry function, device identifier and CRC are present and correct.

This function is used by Brick Viewer during flashing. It should not be necessary to call it in a normal user program.

The following constants are available for this function:

For mode:

  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_BOOTLOADER = 0
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_FIRMWARE = 1
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_BOOTLOADER_WAIT_FOR_REBOOT = 2
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_FIRMWARE_WAIT_FOR_REBOOT = 3
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_FIRMWARE_WAIT_FOR_ERASE_AND_REBOOT = 4

For status:

  • BrickletIndustrialDual020mAV2.BOOTLOADER_STATUS_OK = 0
  • BrickletIndustrialDual020mAV2.BOOTLOADER_STATUS_INVALID_MODE = 1
  • BrickletIndustrialDual020mAV2.BOOTLOADER_STATUS_NO_CHANGE = 2
  • BrickletIndustrialDual020mAV2.BOOTLOADER_STATUS_ENTRY_FUNCTION_NOT_PRESENT = 3
  • BrickletIndustrialDual020mAV2.BOOTLOADER_STATUS_DEVICE_IDENTIFIER_INCORRECT = 4
  • BrickletIndustrialDual020mAV2.BOOTLOADER_STATUS_CRC_MISMATCH = 5
BrickletIndustrialDual020mAV2.GetBootloaderMode() → mode
Output:
  • mode – Type: Byte, Range: See constants

Returns the current bootloader mode, see SetBootloaderMode().

The following constants are available for this function:

For mode:

  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_BOOTLOADER = 0
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_FIRMWARE = 1
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_BOOTLOADER_WAIT_FOR_REBOOT = 2
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_FIRMWARE_WAIT_FOR_REBOOT = 3
  • BrickletIndustrialDual020mAV2.BOOTLOADER_MODE_FIRMWARE_WAIT_FOR_ERASE_AND_REBOOT = 4
BrickletIndustrialDual020mAV2.SetWriteFirmwarePointer(pointer)
Input:
  • pointer – Type: Int64, Unit: 1 B, Range: [0 to 232 - 1]

Sets the firmware pointer for WriteFirmware(). The pointer has to be increased by chunks of size 64. The data is written to flash every 4 chunks (which equals to one page of size 256).

This function is used by Brick Viewer during flashing. It should not be necessary to call it in a normal user program.

BrickletIndustrialDual020mAV2.WriteFirmware(data) → status
Input:
  • data – Type: Byte[64], Range: [0 to 255]
Output:
  • status – Type: Byte, Range: [0 to 255]

Writes 64 Bytes of firmware at the position as written by SetWriteFirmwarePointer() before. The firmware is written to flash every 4 chunks.

You can only write firmware in bootloader mode.

This function is used by Brick Viewer during flashing. It should not be necessary to call it in a normal user program.

BrickletIndustrialDual020mAV2.SetStatusLEDConfig(config)
Input:
  • config – Type: Byte, Range: See constants, Default: 3

Sets the status LED configuration. By default the LED shows communication traffic between Brick and Bricklet, it flickers once for every 10 received data packets.

You can also turn the LED permanently on/off or show a heartbeat.

If the Bricklet is in bootloader mode, the LED is will show heartbeat by default.

The following constants are available for this function:

For config:

  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_OFF = 0
  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_ON = 1
  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_SHOW_HEARTBEAT = 2
  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_SHOW_STATUS = 3
BrickletIndustrialDual020mAV2.GetStatusLEDConfig() → config
Output:
  • config – Type: Byte, Range: See constants, Default: 3

Returns the configuration as set by SetStatusLEDConfig()

The following constants are available for this function:

For config:

  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_OFF = 0
  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_ON = 1
  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_SHOW_HEARTBEAT = 2
  • BrickletIndustrialDual020mAV2.STATUS_LED_CONFIG_SHOW_STATUS = 3
BrickletIndustrialDual020mAV2.GetChipTemperature() → temperature
Output:
  • temperature – Type: Int16, Unit: 1 °C, Range: [-215 to 215 - 1]

Returns the temperature as measured inside the microcontroller. The value returned is not the ambient temperature!

The temperature is only proportional to the real temperature and it has bad accuracy. Practically it is only useful as an indicator for temperature changes.

BrickletIndustrialDual020mAV2.Reset()

Calling this function will reset the Bricklet. All configurations will be lost.

After a reset you have to create new device objects, calling functions on the existing ones will result in undefined behavior!

BrickletIndustrialDual020mAV2.WriteUID(uid)
Input:
  • uid – Type: Int64, Range: [0 to 232 - 1]

Writes a new UID into flash. If you want to set a new UID you have to decode the Base58 encoded UID string into an integer first.

We recommend that you use Brick Viewer to change the UID.

BrickletIndustrialDual020mAV2.ReadUID() → uid
Output:
  • uid – Type: Int64, Range: [0 to 232 - 1]

Returns the current UID as an integer. Encode as Base58 to get the usual string version.

BrickletIndustrialDual020mAV2.GetIdentity() → uid, connectedUid, position, hardwareVersion, firmwareVersion, deviceIdentifier
Output:
  • uid – Type: String, Length: up to 8
  • connectedUid – Type: String, Length: up to 8
  • position – Type: Char, Range: ["a" to "h", "i", "z"]
  • hardwareVersion – Type: Byte[3]
    • 0: major – Type: Byte, Range: [0 to 255]
    • 1: minor – Type: Byte, Range: [0 to 255]
    • 2: revision – Type: Byte, Range: [0 to 255]
  • firmwareVersion – Type: Byte[3]
    • 0: major – Type: Byte, Range: [0 to 255]
    • 1: minor – Type: Byte, Range: [0 to 255]
    • 2: revision – Type: Byte, Range: [0 to 255]
  • deviceIdentifier – Type: Int32, Range: [0 to 216 - 1]

Returns the UID, the UID where the Bricklet is connected to, the position, the hardware and firmware version as well as the device identifier.

The position can be 'a', 'b', 'c', 'd', 'e', 'f', 'g' or 'h' (Bricklet Port). The Raspberry Pi HAT (Zero) Brick is always at position 'i' and the Bricklet connected to an Isolator Bricklet is always as position 'z'.

The device identifier numbers can be found here. There is also a constant for the device identifier of this Bricklet.

Callback Configuration Functions

BrickletIndustrialDual020mAV2.SetCurrentCallbackConfiguration(channel, period, valueHasToChange, option, min, max)
Input:
  • channel – Type: Byte, Range: [0 to 1]
  • period – Type: Int64, Unit: 1 ms, Range: [0 to 232 - 1], Default: 0
  • valueHasToChange – Type: Boolean, Default: F
  • option – Type: Char, Range: See constants, Default: "x"
  • min – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 0
  • max – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 0

The period is the period with which the CurrentCallback callback is triggered periodically. A value of 0 turns the callback off.

If the value has to change-parameter is set to true, the callback is only triggered after the value has changed. If the value didn't change within the period, the callback is triggered immediately on change.

If it is set to false, the callback is continuously triggered with the period, independent of the value.

It is furthermore possible to constrain the callback with thresholds.

The option-parameter together with min/max sets a threshold for the CurrentCallback callback.

The following options are possible:

Option Description
'x' Threshold is turned off
'o' Threshold is triggered when the value is outside the min and max values
'i' Threshold is triggered when the value is inside or equal to the min and max values
'<' Threshold is triggered when the value is smaller than the min value (max is ignored)
'>' Threshold is triggered when the value is greater than the min value (max is ignored)

If the option is set to 'x' (threshold turned off) the callback is triggered with the fixed period.

The following constants are available for this function:

For option:

  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_OFF = "x"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_OUTSIDE = "o"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_INSIDE = "i"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_SMALLER = "<"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_GREATER = ">"
BrickletIndustrialDual020mAV2.GetCurrentCallbackConfiguration(channel) → period, valueHasToChange, option, min, max
Input:
  • channel – Type: Byte, Range: [0 to 1]
Output:
  • period – Type: Int64, Unit: 1 ms, Range: [0 to 232 - 1], Default: 0
  • valueHasToChange – Type: Boolean, Default: F
  • option – Type: Char, Range: See constants, Default: "x"
  • min – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 0
  • max – Type: Int32, Unit: 1 nA, Range: [-231 to 231 - 1], Default: 0

Returns the callback configuration as set by SetCurrentCallbackConfiguration().

The following constants are available for this function:

For option:

  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_OFF = "x"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_OUTSIDE = "o"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_INSIDE = "i"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_SMALLER = "<"
  • BrickletIndustrialDual020mAV2.THRESHOLD_OPTION_GREATER = ">"

Callbacks

Callbacks can be registered to receive time critical or recurring data from the device. The registration is done by assigning a function to a callback property of the device object. The available callback property and their type of parameters are described below.

Note

Using callbacks for recurring events is always preferred compared to using getters. It will use less USB bandwidth and the latency will be a lot better, since there is no round trip time.

event BrickletIndustrialDual020mAV2.CurrentCallback → sender, channel, current
Callback Output:
  • sender – Type: .NET Refnum (BrickletIndustrialDual020mAV2)
  • channel – Type: Byte, Range: [0 to 1]
  • current – Type: Int32, Unit: 1 nA, Range: [0 to 22505322]

This callback is triggered periodically according to the configuration set by SetCurrentCallbackConfiguration().

The parameter is the same as GetCurrent().

Virtual Functions

Virtual functions don't communicate with the device itself, but operate only on the API bindings device object. They can be called without the corresponding IP Connection object being connected.

BrickletIndustrialDual020mAV2.GetAPIVersion() → apiVersion
Output:
  • apiVersion – Type: Byte[3]
    • 0: major – Type: Byte, Range: [0 to 255]
    • 1: minor – Type: Byte, Range: [0 to 255]
    • 2: revision – Type: Byte, Range: [0 to 255]

Returns the version of the API definition implemented by this API bindings. This is neither the release version of this API bindings nor does it tell you anything about the represented Brick or Bricklet.

BrickletIndustrialDual020mAV2.GetResponseExpected(functionId) → responseExpected
Input:
  • functionId – Type: Byte, Range: See constants
Output:
  • responseExpected – Type: Boolean

Returns the response expected flag for the function specified by the function ID parameter. It is true if the function is expected to send a response, false otherwise.

For getter functions this is enabled by default and cannot be disabled, because those functions will always send a response. For callback configuration functions it is enabled by default too, but can be disabled by SetResponseExpected(). For setter functions it is disabled by default and can be enabled.

Enabling the response expected flag for a setter function allows to detect timeouts and other error conditions calls of this setter as well. The device will then send a response for this purpose. If this flag is disabled for a setter function then no response is send and errors are silently ignored, because they cannot be detected.

The following constants are available for this function:

For functionId:

  • BrickletIndustrialDual020mAV2.FUNCTION_SET_CURRENT_CALLBACK_CONFIGURATION = 2
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_SAMPLE_RATE = 5
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_GAIN = 7
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_CHANNEL_LED_CONFIG = 9
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_CHANNEL_LED_STATUS_CONFIG = 11
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_WRITE_FIRMWARE_POINTER = 237
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_STATUS_LED_CONFIG = 239
  • BrickletIndustrialDual020mAV2.FUNCTION_RESET = 243
  • BrickletIndustrialDual020mAV2.FUNCTION_WRITE_UID = 248
BrickletIndustrialDual020mAV2.SetResponseExpected(functionId, responseExpected)
Input:
  • functionId – Type: Byte, Range: See constants
  • responseExpected – Type: Boolean

Changes the response expected flag of the function specified by the function ID parameter. This flag can only be changed for setter (default value: false) and callback configuration functions (default value: true). For getter functions it is always enabled.

Enabling the response expected flag for a setter function allows to detect timeouts and other error conditions calls of this setter as well. The device will then send a response for this purpose. If this flag is disabled for a setter function then no response is send and errors are silently ignored, because they cannot be detected.

The following constants are available for this function:

For functionId:

  • BrickletIndustrialDual020mAV2.FUNCTION_SET_CURRENT_CALLBACK_CONFIGURATION = 2
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_SAMPLE_RATE = 5
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_GAIN = 7
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_CHANNEL_LED_CONFIG = 9
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_CHANNEL_LED_STATUS_CONFIG = 11
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_WRITE_FIRMWARE_POINTER = 237
  • BrickletIndustrialDual020mAV2.FUNCTION_SET_STATUS_LED_CONFIG = 239
  • BrickletIndustrialDual020mAV2.FUNCTION_RESET = 243
  • BrickletIndustrialDual020mAV2.FUNCTION_WRITE_UID = 248
BrickletIndustrialDual020mAV2.SetResponseExpectedAll(responseExpected)
Input:
  • responseExpected – Type: Boolean

Changes the response expected flag for all setter and callback configuration functions of this device at once.

Constants

BrickletIndustrialDual020mAV2.DEVICE_IDENTIFIER

This constant is used to identify a Industrial Dual 0-20mA Bricklet 2.0.

The GetIdentity() function and the IPConnection.EnumerateCallback callback of the IP Connection have a deviceIdentifier parameter to specify the Brick's or Bricklet's type.

BrickletIndustrialDual020mAV2.DEVICE_DISPLAY_NAME

This constant represents the human readable name of a Industrial Dual 0-20mA Bricklet 2.0.
